Detail

According to their name, these pipe flanges slip over the pipe, that is why it is called slip-on flange. It is fabricated with an inside diameter that is bigger than the pipe’s outside distance across. These connections are associated with the pipe by means of filet weld at the top and base of the flange. Slip on pipe flanges are used with a raised or flat face. At the time of raised face, the standard height would be 1/16" for slip on pipe flanges under 400# while for slip on pipe flanges of 400#, the standard height would be 1/4".

The Slip On pipe flanges include materials carbon steel slip-on pipe flanges, stainless steel slip on pipe flanges and alloy steel slip on pipe flanges available in various class such as 150 LBS, 300 LBS, 600 LBS, 900 LBS. These flanges are ideal for low pressure applications.

Dimentions:
